Long-life Tubular Solenoids

Categories: ,

Description

Kelco Industries’ Long-life Tubular Solenoids incorporate anti-bottoming features, a stainless steel plunger sleeve, and Teflon-coated plungers to increase mechanical life. The anti-bottoming ring and washers prevent the plunger from hitting the plug, eliminating destructive shock forces. The stainless steel plunger sleeve boosts life expectancy over standard thermoplastic cores. The Teflon coating reduces friction and wear between the plunger and the core providing high performance and long life in critical applications. Our long-life tubular solenoids are supplied with a mounting bracket, hex nut, and lock washer. Plungers can be easily customized to interface with your application.

Advantages:

  • Custom voltages available
  • Value added packages
  • Custom plungers
  • Spring returns
  • Custom mounting
  • Custom lead wire terminations

All catalog solenoids are UL Recognized and RoHS compliant (2011/65/EU)
100% Made in the USA

Applications

  • Ventilator Equipment
  • Centrifuges
  • Pinch Valves
  • Blood Analyzers
  • Autoclaves
  • Pill Dispensers
  • Fluid Dispensing
  • Imaging
  • Mobile Drug Carts
  • Door Locks
  • Drawer Locks
  • Cabinet Locks
  • Turnstile Locks
  • Security Gate Locks
  • Business Machines
  • Computers
  • Testing Equipment
  • Aerospace

Pull Type Tubular

Long Life
Tubular Solenoids
Dia in [mm] L in [mm] Max Stroke in
[mm]
*Cont Duty oz [N] *Int Duty oz [N] Datasheet 3D Model
LT3.5×9 0.438 [11.1] 1.15 [29.2] 0.25 [6.4] 1.5 [0.4] 2 [0.6]
LT4x7 0.5 [12.7] 0.89 [22.6] 0.25 [6.4] 2 [0.6] 3 [0.8]
LT4x12 0.5 [12.7] 1.5 [38.1] 0.375 [9.5] 3 [0.8] 8 [2.2]
LT4x16 0.5 [12.7] 2.01 [51.1] 0.375 [9.5] 3 [0.8] 7 [1.9]
LT6x12 0.75 [19.1] 1.54 [39.1] 0.5 [12.7] 5 [1.4] 10 [2.8]
LT8x9 1 [25.4] 1.17 [29.7] 0.5 [12.7] 5 [1.4] 10 [2.8]
LT8x16 1 [25.4] 2.04 [51.8] 0.75 [19.1] 9 [2.5] 25 [7]
LT12x13 1.5 [38.1] 1.63 [41.4] 0.75 [19.1] 15 [4.2] 40 [11.1]
LT12x19 1.5 [38.1] 2.43 [61.7] 1 [25.4] 18 [5] 40 [11.1]
